Champion Quick-Lock Mounting Bracket - Strut, Wall and Teardrop Hanging (14mm to 63mm)

Aluminum pipe is one tenth the weight of the same diameter steel, which is exactly why how you support it matters. A Champion Quick-Lock mounting bracket holds the tube at a fixed spacing off the structure, keeps a long run straight, and lets the pipe move a little as temperature changes rather than fighting it.

This listing carries Champion's full bracket range in one place: strut brackets in packs of ten for channel and wall work, wall brackets with spacer sold individually, teardrop hanging brackets with a 3/8 in insert for overhead runs, a flush wall mount for 14mm, and the deep wall spacer kit for standing a run further off an uneven surface.

Choose your bracket and size from the dropdown above.

Which Bracket for Which Job

Model Selection Chart

Note the pack sizes. Strut brackets and the 14mm flush mount come ten to a pack; wall brackets, teardrop hangers and the deep wall spacer are sold individually. On a whole-shop install the packs are where the value is.

Do Not Clamp a Long Run Rigidly

Aluminum expands and contracts at 0.024 mm per metre per degree C. Over a hundred-foot straight run in a building that swings from winter mornings to summer afternoons, that movement is real and it has to go somewhere. Champion's own installation guidance is that brackets clip the tube securely to a wall or hang it from the ceiling and around beams, and that both the bracket and the tube stay adjustable.

In practice: fix the run at a sensible anchor point, then let the remaining brackets locate the pipe without pinching it, and give the system room to breathe at direction changes. A run that is bolted down hard at every point will push on its own fittings.

Shared Technical Specifications

Ideal Applications

Running a main along a shop wall, carrying a loop around the perimeter of a building, hanging a header from an open ceiling or from roof structure, dropping a branch down a column, supporting bench and station runs in 14mm, and retrofitting support into a building where the only available structure is strut channel already on the wall.

Building a Complete Quick-Lock System

• Quick-Lock aluminum tubing, 14mm to 63mm
• Wire hangers, cantilever wall brackets and beam clamps for overhead runs
• Outlet manifolds for the drop stations the brackets carry
• 90 and 45 degree elbows and street elbows
• Equal tees and reduction outlet tees
• Tube cutter, deburring tools, marking gauge and wrench sets

Ordering Notes

• All Quick-Lock products and accessories are NO CANCEL / NO RETURN, per Champion's current price list.
• Freight: freight collect from Huntersville, NC 28078 or Las Vegas, NV 89113.
• Shipping weights: Champion publishes no weight for the Quick-Lock accessory range, so no catalog weight is carried on these variants.

Why Buy from Air Compressor Store

Air Compressor Store is an authorized Champion Pneumatic distributor. Bracket count is the line most people underestimate on a take-off, and running short halfway through a Saturday install is how a one-weekend job becomes a two-weekend job. Send us the layout and the structure you are fixing to, and we will count them properly.

Frequently Asked Questions

How far apart should the brackets go?

It depends on tube size, whether the run is horizontal or vertical, and what the structure gives you to fix to. Champion does not publish a single span table in the current literature, so rather than quote a number we would not stand behind, send us your run and we will advise. As a general principle, aluminum is light but a long unsupported span will sag visibly and that sag loads the fittings.

What is the difference between the strut bracket and the wall bracket?

The strut bracket is the general-purpose mount, sold in packs of ten, and it fastens to strut channel or directly to a surface. The wall bracket comes with a spacer that holds the pipe off the wall, is sold individually, and suits the handful of positions where you need standoff rather than a bulk run.

Can I hang the pipe from the ceiling with these?

Use the teardrop hanging bracket, which takes a 3/8 in insert and so accepts threaded rod, a Champion wire hanger or a beam clamp. The strut and wall brackets are for fixing to a surface.

Why are the strut brackets sold in tens and the wall brackets singly?

That is how Champion packages them, and it matches how they get used. A whole-shop run eats strut brackets by the dozen; wall brackets and teardrop hangers tend to be specified a few at a time for particular positions.

Do the brackets fit over the fittings as well as the tube?

They are sized to the tube outside diameter. Place brackets on tube, not on a union, elbow or tee body, and keep a bracket reasonably close to each side of a heavy fitting so its weight is not hanging on the pipe.

What does the deep wall spacer do?

It stands a strut bracket further off the wall, which is what you want on block, brick or an uneven surface, or where something else is already on the wall in the way. It is 1 x 3 x 1/2 in thick and comes with a 1/4 in x 20 x 1 in threaded rod stud.

Will these fit another brand of aluminum pipe?

Do not assume so. The clamp profile is sized to Champion's tube outside diameter. If you are extending an existing system someone else installed, send us a photo and we will identify what is on the wall.
