Collection: Coalescing Air Filters

A general purpose particulate filter is rated around 1 micron and leaves up to 0.5 mg per cubic meter of oil in the air. A coalescing filter takes that to 0.01 micron and 0.01 mg per cubic meter. That's the difference, and on oil carryover it's a factor of fifty.

Inside the element is a dense mat of fine fibers. Submicron oil and water droplets collide with the fibers and stick, the droplets merge into drops large enough for gravity to move, and those drops fall to the bottom of the housing and leave through the drain. The air keeps going. The oil doesn't.

Where a coalescing filter stops

It removes liquid oil and aerosol. It does not remove oil vapor, which passes straight through. Vapor is an activated carbon job, and carbon only lasts if a coalescer upstream is doing its work. A coalescing filter is also not a dryer. It catches water that has already condensed, but it will not lower your dew point by one degree, so if you're buying one because water keeps coming out of your lines, you're buying the wrong part and you want a refrigerated or desiccant dryer.

Sizing and staging

Order matters: particulate filter first to catch scale and rust, coalescer second, dryer third. Run it the other way around and the coalescing element loads up with pipe scale in a matter of weeks.

Size by SCFM at your operating pressure, never by pipe thread. A 1 inch port doesn't mean the housing flows what your compressor makes, and an undersized filter is a permanent pressure drop you pay for every hour it runs. A clean element sits around 1 to 2 PSID; change it at 5, or annually, whichever lands first. Every 2 PSI of pressure drop costs roughly 1 percent of compressor energy, which is why running elements until they plug is a tax rather than a savings.

This collection carries housings, replacement elements for common industrial bodies, and versions with automatic drains. The drain matters more than people expect. A coalescer with a plugged drain re-entrains everything it just collected and sends it downstream.
