Prevost Aluminum 90° Union Compression Elbow Fitting For Air Pipe
Prevost Aluminum 90° Union Compression Elbow Fitting For Air Pipe
| Specifications (As Configured) | |
|---|---|
 Vendor |
Prevost
|
 SKU |
PPS1 9C16
|
| Dimensions | |
 Weight |
0.17 lb
|
Dimension |
|
Shipping Height |
|
Shipping Length |
|
Shipping Width |
|
| Downloadable Files | |
 Brochure PDF |
|
 Technical Data |
|
Made from high-quality aluminum, this durable fitting allows for a seamless 90-degree transition between Prevost air pipes, ensuring optimal airflow and leak-free performance. Its compression design provides a tight, reliable seal without the need for additional sealing compounds.
PPS1 9C – 90 deg. ALUMINUM UNION ELBOW FITTING FOR ALUMINUM AIR PIPE
Enhance your compressed air system with the Prevost 90° Compression Union Elbow Air Pipe Fitting, designed for secure and efficient connections. Made from high-quality aluminum, this durable fitting allows for a seamless 90-degree transition between Prevost air pipes, ensuring optimal airflow and leak-free performance. Its compression design provides a tight, reliable seal without the need for additional sealing compounds. Ideal for industrial and commercial pneumatic applications, this fitting is built to withstand demanding environments
Technical specifications
- Technology: PPS Grip Concept
- Operating pressure: 29 to 232 psi
- Vacuum capability: 0.59 inHg (vacuum 98%)
- Temperature: 5 deg. F to158 deg. F
- Construction: Pipe and fittings: alu.
- Highlight: Scalable system
- Meets standards: ASME B31.3 REACH
| Reference | For pipe OD (in) | A inch | B inch | B inch |
|---|---|---|---|---|
| PPS1 9C16 | 1/2″ | 0.1049868766 | 0.2034120735 | 0.3264435696 |
| PPS1 9C20 | 3/4″ | 0.124671916 | 0.2395013123 | 0.1607611549 |
| PPS1 9C25 | 1″ | 0.1509186352 | 0.2919947507 | 0.1738845144 |
| PPS1 9C32 | 1 1/4″ | 0.187007874 | 0.3477690289 | 0.187007874 |
| PPS1 9C40 | 1 1/2″ | 0.2230971129 | 0.4429133858 | 0.3264435696 |
| PPS1 9C50 | 2″ | 0.2755905512 | 0.4954068241 | 0.342847769 |
| PPS1 9C63 | 2 1/2″ | 0.3280839895 | 0.5905511811 | 0.4429133858 |
| PPS1 9C80 | 3″ | 0.3969816273 | 0.7152230971 | 0.4757217848 |
| PPS1 9C100 | 4″ | 0.5036089239 | 0.7349081365 | 0.5085301837 |
NOTE: Actual product may be different from pictured!
