ABAC AS-7.5251TM7 7.5 HP Rotary Screw Air Compressor - 71 Gallon Tank Mount, 125 PSI, 30.5 CFM, 67 dBA

The ABAC AS-7.5251TM7 is the 7.5 HP AS-B rotary screw delivered as a finished package: the compressor, the controller and a 71 gallon ASME air receiver on one skid, wired and plumbed, so installation is a power drop and a line out. It makes 30.5 CFM at a 125 PSI maximum and runs at 67 dBA, quiet enough to live in the work area rather than a separate compressor room. A rotary screw is rated for continuous duty, so unlike a piston machine it does not need to rest between jobs, and the 71 gallon receiver is there to smooth demand rather than to be the air supply. Choose 230V single-phase (AS-7.5251TM, part 4152044121) or 208-230-460V three-phase (AS-7.5253TM, part 4152043891).

Key specifications

• Models: AS-7.5251TM / AS-7.5253TM (store reference AS-7.5251TM7)
• Motor: 7.5 HP, direct drive to an integrated aluminum block air end
• Air delivery: 30.5 CFM
• Maximum pressure: 125 PSI
• Noise level: 67 dBA
• Receiver: 71 gallon tank mount
• Power supply: 230/1/60 or 208-230-460/3/60
• Weight: 507 lbs
• Dimensions: 63 x 23 x 57 in
• Digital controller with menu driven operation and programmed maintenance
• Eco-friendly vertical oil separation technology
• Duty cycle: 100 percent, continuous running

CFM measured per ISO 1217 Annex C, quoted at 109 PSI for 125 PSI maximum units. Noise measured per ISO 2151:2004 using ISO 9614/2.

How it compares

Inside the AS-B 7.5 HP range the air end is the same and the configuration is what changes. The base mount AS-7.5251BM is the same compressor with no tank at 360 lbs and 32 x 24 x 40 in, for shops that already own a receiver. Step up to the larger tank mount at 655 lbs if demand is spiky and you want more stored air. The AS-7.5251TMD7 with integrated dryer adds refrigerated drying on the same 71 gallon footprint at 593 lbs. Pressure is the other axis: the 150 PSI build of this same machine trades flow for line pressure, 27.1 CFM instead of 30.5 CFM. If 30.5 CFM is already tight, the 10 HP AS-10253TM7 gives 36.4 CFM on the same 71 gallon platform.

Typical applications

Automotive service and tire bays running impacts and lifts all day, small fabrication and welding shops, cabinet and woodworking shops running sanders and nailers, auto body and finishing work, and any operation where a piston compressor is cycling hard enough to overheat or to keep the shop loud. At 30.5 CFM this machine comfortably covers two or three technicians on intermittent tools, a single sander or orbital, or a small plasma cutter. Sandblasting and multiple simultaneous impact wrenches want more air; size up from the rotary screw range for that work.

Installation and air treatment

Leave roughly 3 feet of clearance on the cooling air side, keep the room between 40 and 104 F, and run the unit on a dedicated circuit sized to the motor nameplate. Oil, oil filter and separator element are the scheduled service items and the controller tracks the intervals for you. A screw compressor discharges warm, saturated air, so if that air reaches paint, tires, pneumatic controls or anything that dislikes moisture, pair this unit with a dryer sized above its output: the ABAC COOL 35 refrigerated dryer at 35 CFM covers 30.5 CFM with headroom, and the full refrigerated air dryer range runs from 15 to 250 CFM.

Part of the ABAC AS-B 5 to 20 HP screw range from the Atlas Copco group. Browse the rest of our rotary screw air compressors or the wider range of stationary air compressors.
