WEG RW67-5D2 2-Pole Thermal Overload Relay — Class 10, for CWB40–CWB80 Contactors
The WEG RW67-5D2 is a 2-pole bi-metallic thermal overload relay sized for larger motor circuits, protecting against overload, phase loss, and current imbalance. It mounts directly onto WEG CWB40 through CWB80 IEC contactors (40–80 A frame) or can be panel-mounted with a separate-mounting kit. Each model covers a specific, infinitely adjustable trip-current band — choose the band that brackets your motor's full-load amps (FLA).
Key specifications
- 2-pole bi-metallic thermal overload relay
- Trip Class 10 (trips within set time at 1.5× the dial setting)
- Infinitely adjustable current dial — set to the motor FLA
- Phase-loss / phase-unbalance sensitivity
- Ambient temperature compensation, approx. -13°F to +140°F (-25°C to +60°C)
- Selectable Manual / Automatic reset, with TEST and STOP functions
- Isolated auxiliary contacts: 1 N.O. + 1 N.C.
- Rated insulation voltage 690 V (IEC 60947), 600 V (UL/CSA)
- Operating frequency 50/60 Hz (rated up to 400 Hz)
- Direct mount to WEG CWB40–CWB80 contactors (40–80 A)
Typical applications
Used in motor-starter and control-panel builds for larger pumps, fans, compressors, conveyors, and general-purpose AC motors where reliable overload and single-phasing protection is required.
Pair the WEG RW67-5D2 Class 10 thermal overload relay with a matching WEG CWB40–CWB80 contactor to build a robust, code-compliant motor starter. Select the setting range that matches your motor's full-load current for accurate, dependable overload protection.
NOTE: Actual product may be different from pictured!
