PIC 1-1/2" Liquid-Filled Pressure Gauge — U-Clamp Panel Mount, 1/8" NPT Center Back
| Specifications (As Configured) | |
|---|---|
 Vendor |
PIC Gauges
|
 SKU |
203L-158B
|
The Warthog 1-1/2" liquid-filled pressure gauge (PIC 203L series) is a compact, panel-ready instrument built for compressed-air, hydraulic, and fluid-power equipment exposed to vibration and pressure pulsation. The glycerine fill dampens needle flutter for a steady, easy-to-read indication and extends service life in demanding conditions, while the U-clamp bracket makes for fast center-back panel mounting.
Which range should you choose?
This model is offered as positive-pressure ranges plus one vacuum gauge:
- Pressure (e.g. 0–100 PSI): Positive pressure only — what almost every air-compressor and shop-air job needs. Pick a range where your normal working pressure sits around the middle of the dial.
- Vacuum only (0 to 30 inHg): Suction / negative pressure only.
What does "inHg" mean? It stands for inches of mercury — the standard unit gauges use to measure vacuum, meaning pressure below normal atmospheric pressure (in other words, suction). 0 inHg is ordinary atmospheric pressure, and about 30 inHg is a near-complete vacuum — roughly 14.7 PSI of suction. So a gauge marked "30 inHg" reads the entire vacuum range, from no suction down to full vacuum. (By comparison, PSI measures pressure above atmospheric.)
Key specifications
- Dial size: 1-1/2" (40 mm)
- Connection: 1/8" NPT, center back mount
- Mounting: U-clamp panel mount bracket
- Case & bezel: 304 stainless steel
- Internals: brass / copper alloy Bourdon tube and movement
- Lens: polycarbonate
- Fill: glycerine (liquid filled)
- Accuracy: ±3-2-3% of span (ASME B40.100 Grade B)
- Operating temperature: 30°F to 160°F
- Pressure ranges: 30 inHg vacuum through 0-5000 PSI
Typical applications
Air compressors and receiver tanks, pneumatic control panels, hydraulic power units, pumps, filtration and process skids, and any application where vibration would shorten the life of a dry gauge.
Available in 13 pressure ranges from a 30 inHg vacuum gauge up to 0-5000 PSI, the Warthog 1-1/2" liquid-filled panel-mount gauge delivers reliable, vibration-resistant pressure indication with a corrosion-resistant stainless steel case and 1/8" NPT center-back connection.
NOTE: Actual product may be different from pictured!
