IronAir Series Tank Mounted Cast Iron Reciprocating Air Compressor By Mark
| Specifications (As Configured) | |
|---|---|
 Vendor |
Mark
|
 SKU |
8090303192
|
 Model |
|
Gallons |
|
 Material |
|
 Voltage |
|
 Phase |
|
| Dimensions | |
 Weight |
515.0 lb
|
The Mark IronAir Series is a full cast iron, two-stage reciprocating air compressor built for shops that run air all day. Cast iron cylinders, an oversized flywheel for pump cooling, and an oil sight glass for quick checks. Available 5 HP through 20 HP, simplex or duplex, on 80 or 120 gallon ASME tanks.
Specifications by model
| SKU | HP | Package | Tank | Voltage | Pump | ACFM @ 175 PSI | Ship Weight |
|---|---|---|---|---|---|---|---|
| 8090303192 | 5 HP | Simplex | 80 Gallon Vertical | 208-230V / 1 Phase | C1 cast iron, 2-cylinder in-line | 16 | 489 lbs |
| 8090303200 | 5 HP | Simplex | 80 Gallon Vertical | 208-230V / 3 Phase | C1 cast iron, 2-cylinder in-line | 16 | 489 lbs |
| 8090303218 | 7.5 HP | Simplex | 80 Gallon Vertical | 208-230V / 1 Phase | C1 cast iron, 2-cylinder in-line | 21 | 489 lbs |
| 8090303226 | 7.5 HP | Simplex | 80 Gallon Vertical | 208-230V / 3 Phase | C1 cast iron, 2-cylinder in-line | 21 | 489 lbs |
| 8090303317 | 10 HP | Simplex | 120 Gallon Horizontal | 208-230V / 3 Phase | C2 cast iron, 4-cylinder V | 32 | 850 lbs |
| 8090303234 | 10 HP | Duplex | 120 Gallon Horizontal | 460V / 3 Phase | Two C1 cast iron, 2-cylinder in-line | 32 | 1,150 lbs |
| 8090303242 | 15 HP | Duplex | 120 Gallon Horizontal | 460V / 3 Phase | Two C1 cast iron, 2-cylinder in-line | 42 | 1,200 lbs |
| 8090303259 | 20 HP | Duplex | 120 Gallon Horizontal | 460V / 3 Phase | Two C2 cast iron, 4-cylinder V | 64 | 1,600 lbs |
Standard Features
- Solid cast iron cylinders to promote long life
- Two-stage pump, 175 PSI maximum working pressure
- Easy-to-read oil sight glass
- Oversized flywheel to cool pump components
- Extended oil drain to simplify oil changes
- High volumetric efficiency maximizes air delivery
- ASME-coded air receiver
Choosing a model
The 80 gallon vertical simplex units are the only single-phase machines in the line, at 5 HP and 7.5 HP. Everything on the 120 gallon horizontal tank is three phase. The 10 HP simplex and the 20 HP duplex use the C2 four-cylinder V pump; the rest use the C1 two-cylinder in-line pump.
Where it fits
Automotive and fleet service bays, fabrication and welding shops, general manufacturing, and maintenance departments running air tools through the full workday. Duplex units give you two pumps on one tank for redundancy and staged capacity.
Mark is an Atlas Copco brand. Need a voltage or configuration not shown here? Contact us and we will quote it.
NOTE: Actual product may be different from pictured!
