Eaton 9 A 3-Phase IEC Magnetic Motor Starter — 480V, 5 HP, 6–10 A Overload (XT Series)
| Specifications (As Configured) | |
|---|---|
 Vendor |
Eaton
|
 SKU |
ECX09C1CAA-J
|
The Eaton ECX09 is a 9 A three-phase, non-reversing IEC magnetic motor starter from the Eaton XT series, factory-assembled in a NEMA 1 enclosure for dependable across-the-line starting and overload protection of smaller three-phase motors. It pairs an XT IEC contactor with an adjustable electronic overload relay set for 6–10 A, making it a reliable motor control for air compressors, pumps, fans, and similar industrial loads.
Key specifications
- Brand: Eaton — XT series
- Type: IEC magnetic motor starter, non-reversing (FVNR), 3-pole / 3-phase
- Contactor rating: 9 A
- Overload protection: electronic overload relay, 6–10 A adjustable, Trip Class 10
- Coil voltage: 480V
- Horsepower (3-phase): 5 HP @ 480V
- Auxiliary contacts: 1 N/O + 1 N/C included
- Enclosure: NEMA 1 / IP23, surface mount
- Cover controls: none (blank cover)
- Frequency: 50/60 Hz · Max voltage: 690 V AC
- Listings: UL Listed, cUL Listed
Cover controls
This starter ships with a blank cover. There are no start/stop pushbuttons, no selector switch and no pilot lights on the enclosure. In the Eaton catalog number the ninth character sets the cover control, and an A in that position means no cover-mounted pilot devices. Photos of the ECX09 family are representative and may show a cover fitted with pushbuttons or a selector switch.
To add operator controls in the field, order the Eaton C400GK1 START/STOP pushbutton cover control kit or the C400GK3 Hand/Off/Auto selector switch kit (Type 1 enclosures, Box 2 and larger; C600M1 on the smallest Box 1 enclosures). You can also wire an external start/stop station to the coil using the included N/O auxiliary contact as the seal-in, or run 2-wire control straight off a compressor pressure switch.
Typical applications
Across-the-line starting and overload protection for three-phase air compressors, pumps, blowers, fans, conveyors, and general industrial machinery.
The Eaton ECX09 9 A XT-series IEC magnetic motor starter delivers factory-built 480V motor control for 5 HP three-phase loads in a rugged NEMA 1 enclosure with an adjustable 6–10 A electronic overload.
NOTE: Actual product may be different from pictured!
