Eaton 18 A 3-Phase IEC Magnetic Motor Starter — 12–16 A Overload (XT Series, NEMA 1)
| Specifications (As Configured) | |
|---|---|
 Vendor |
Eaton
|
 SKU |
ECX09F1BAA-L
|
The Eaton ECX09 is an 18 A three-phase, non-reversing IEC magnetic motor starter from the Eaton XT series, factory-assembled in a NEMA 1 enclosure for dependable across-the-line starting and overload protection of three-phase motors. It pairs an XT IEC contactor with an adjustable electronic overload relay set for 12–16 A, making it a reliable motor control for air compressors, pumps, fans, and similar industrial loads.
Key specifications
- Brand: Eaton — XT series
- Type: IEC magnetic motor starter, non-reversing (FVNR), 3-pole / 3-phase
- Contactor rating: 18 A
- Overload protection: electronic overload relay, 12–16 A adjustable, Trip Class 10
- Coil voltages available: 240V, 480V (select below)
- Horsepower (3-phase): 5 HP @ 240V · 10 HP @ 480V
- Auxiliary contacts: 1 N/O + 1 N/C included
- Enclosure: NEMA 1 / IP23, surface mount
- Cover controls: none (blank cover)
- Frequency: 50/60 Hz · Max voltage: 690 V AC
- Listings: UL Listed, cUL Listed
Cover controls
This starter ships with a blank cover. There are no start/stop pushbuttons, no selector switch and no pilot lights on the enclosure. In the Eaton catalog number the ninth character sets the cover control, and an A in that position means no cover-mounted pilot devices. Photos of the ECX09 family are representative and may show a cover fitted with pushbuttons or a selector switch.
To add operator controls in the field, order the Eaton C400GK1 START/STOP pushbutton cover control kit or the C400GK3 Hand/Off/Auto selector switch kit (Type 1 enclosures, Box 2 and larger; C600M1 on the smallest Box 1 enclosures). You can also wire an external start/stop station to the coil using the included N/O auxiliary contact as the seal-in, or run 2-wire control straight off a compressor pressure switch.
Typical applications
Across-the-line starting and overload protection for three-phase air compressors, pumps, blowers, fans, conveyors, and general industrial machinery.
The Eaton ECX09 18 A XT-series IEC magnetic motor starter delivers factory-built motor control in a rugged NEMA 1 enclosure with an adjustable 12–16 A electronic overload, available with 240V or 480V coils to match your three-phase motor.
NOTE: Actual product may be different from pictured!
