Champion CDV4 Series Motorized Ball Valve Condensate Drain (600 PSIG)

The Champion CDV4 Series is a motorized ball valve condensate drain designed for the drain points that defeat ordinary solenoid drains: high pressure systems, heavy rust and sludge loading, and outdoor installations. Instead of a small solenoid orifice, the CDV4 uses an electric actuator to rotate a full bore ball valve open and closed, so the discharge path is the full size of the port and debris passes straight through it.

Select your port size from the dropdown above.

Why a Motorized Ball Valve

Solenoid drains fail in dirty service for one reason: the seat orifice is small, and rust scale, carbon and pipe sludge eventually wedge it open or hold it shut. A drain wedged open bleeds compressed air continuously. A drain held shut floods the vessel it was meant to protect and carries liquid downstream into tools and finishes. The CDV4 sidesteps both failure modes. A quarter turn actuator swings a ball valve through its full bore on every cycle, which both clears the passage and gives debris somewhere to go.

The second reason to specify a CDV4 is pressure. Most electric drains top out near 200 PSIG. The CDV4 is rated for systems up to 600 PSIG, which puts high pressure plant air, PET blowing lines and breathing air compressor rooms squarely inside its range.

Model Selection Chart

Choose the port size to match the drain connection on the vessel and the volume of condensate it collects. The 1" CDV4-18 is the usual choice on large receivers, wet tanks and high volume aftercoolers; the 1/2" CDV4-14 covers filters, separators, dryer sumps and smaller receivers.

Key Features at a Glance

• 600 PSIG Maximum Pressure - Built for heavy duty and high pressure applications well beyond the reach of a standard solenoid drain.
• Full Bore Ball Valve - Passes rust, scale, carbon and sludge that plug a small solenoid orifice.
• Microprocessor Control, 10 Programmable Settings - Dial in the open and closed intervals to the actual condensate load instead of accepting a fixed cycle.
• Weatherproof Enclosure - Rated for indoor or outdoor installation, including unheated compressor sheds and rooftop equipment.
• Battery Backup - Retains operation through a power failure rather than leaving the drain dead until someone notices.
• Double O-Ring Shaft Seal - Two seals on the valve shaft, the classic leak path on a motorized valve.
• Corrosion Resistant Valve Coating - Protects the valve body against acidic compressed air condensate.
• Manual Test Button and Visual Indicators - Cycle the valve by hand and confirm at a glance whether the drain is powered and whether the valve is open.
• Made in the U.S.A.

Shared Technical Specifications

Ideal Applications

Specify a CDV4 on high pressure plant air above 200 PSIG, on large air receivers and wet tanks where a season of rust scale would plug a solenoid, on aftercooler and cyclone separator drains carrying heavy carbon, on outdoor and unheated installations, and anywhere a plugged drain has already caused a quality problem or a tool failure. It is also the right answer when a maintenance crew is tired of rebuilding solenoid drains two and three times a year.

Selecting Between Champion Drain Types

Installation and Service

Pipe the CDV4 below the vessel it drains so condensate reaches it by gravity, and install a full port isolation valve upstream so the drain can be serviced with the system running. Run the discharge to an oil water separator rather than to a floor drain, since compressed air condensate carries lubricant and is regulated waste in most jurisdictions. Set the open time just long enough to clear the collected liquid, then extend the closed interval until the drain is discharging liquid rather than air on each cycle. Verify operation with the test button at every scheduled service.

Why Buy from Air Compressor Store

Air Compressor Store is an authorized Champion Pneumatic distributor. Every CDV4 drain ships with the full factory warranty, lifetime application support, and access to our compressed air engineers for drain sizing and condensate management design.

Frequently Asked Questions

How is this different from an electronic timer drain?

A timer drain opens a small solenoid orifice on a fixed schedule. The CDV4 rotates a full bore ball valve, so it passes debris that would plug a solenoid and it holds a far higher pressure rating. The programmable control still lets you set open and closed intervals the way a timer drain would.

What pressure can it handle?

Up to 600 PSIG, which is roughly three times the limit of a typical solenoid drain.

Does it lose compressed air when it cycles?

Yes, like any timed drain it vents some air during the open interval. Tune the open time down to the minimum that clears the condensate. If zero air loss is the priority and the condensate is clean, use the CDV1 demand drain instead.

Which size should I order?

Match the port to the vessel's drain connection and the condensate volume. The 1" CDV4-18 suits large receivers and high volume aftercoolers; the 1/2" CDV4-14 suits filters, separators, dryer sumps and smaller receivers.

Will it work outdoors?

Yes. The enclosure is weatherproof and rated for indoor or outdoor operation, and the battery backup keeps the control alive through a power interruption.

What voltage does it need?

115 volt single phase, 50 or 60 Hz, on both models.
