Warthog Brass Hose Barb to Dual 45°/37° Flare Swivel Adapter
The Warthog Brass Hose Barb to Dual 45°/37° Flare Swivel Adapter connects a push-on or clamped hose to a flared tube line, with a captive female swivel nut that lets you tighten the connection without twisting the hose. Its dual-angle seat mates with both 45° SAE and 37° JIC male flares, so a single fitting covers two of the most common flare standards.
Machined from solid brass for corrosion resistance and reliable sealing in air, fuel, lubricant, coolant, and light oil lines. Ideal for low-pressure compressed-air plumbing, automotive, and general shop hose assemblies.
Key specifications
- Body: Solid brass (CA360/CA377)
- Barb end: Hose barb for push-on / clamp-style hose
- Swivel end: Female swivel nut, dual 45° SAE / 37° JIC flare seat
- Available hose IDs: 3/16", 1/4", 5/16", 3/8", 1/2", 5/8"
- Flare sizes: 1/4", 5/16", 1/2", 5/8"
- Swivel thread: 7/16-20, 1/2-20, 3/4-16, 7/8-14 UNF
- Typical rating: low-pressure service, approx. 150 PSI, -40°F to +160°F
Applications
Compressed-air lines, fuel and oil transfer, lubrication systems, coolant lines, and automotive hose connections where a hose must join a 45° SAE or 37° JIC flared tube.
Select your size below by hose ID, flare size, and swivel thread. The swiveling nut makes installation and service quick — connect the barb to your hose, then thread and tighten the swivel onto the flare without kinking or torquing the hose.
NOTE: Actual product may be different from pictured!
