BALDOR 7.5 HP Air Compressor Motor 215T FRAME 208-230v REVERSIBLE

215T | 1740RPM | 1-3/8 Shaft | 34.0-28.6 Amps | 208-230 Volts | 1.15(1.00@208v) - Need Help? Text us Photos! NEED HELP FINDING A REPLACEMENT MOTOR? EMAIL OR TEXT US A PICTURE OF THE DATA PLATE OF THE MOTOR YOU ARE REPLACING. IF THE NAMEPLATE IS NOT AVAILABLE, PLEASE LET US KNOW THE FOLLOWING CRITERIA SO WE CAN PROPERLY SIZE THE MOTOR YOU NEED.
- HP - FRAME SIZE - RPM - PHASE - VOLTAGE - ENCLOSURE TYPE(ODP OR TEFC) - SHAFT DIAMETER - SERVICE FACTOR
PLEASE NOTE: NEVER ASSUME THE INCOMING VOLTAGE. ALWAYS CHECK INCOMING VOLTAGE BEFORE ORDERING A REPLACEMENT MOTOR.

Frame: 215T
RPM: 1740
Shaft Diameter: 1-3/8
Full Load Amp: 34.0-28.6
Voltage: 208-230
Service Factor: 1.15(1.00@208v)
Phase: 1

Baldor 7.5 HP Air Compressor Motor – 215T Frame, 208-230V, Reversible

The Baldor 7.5 HP Air Compressor Motor with a 215T frame is engineered for demanding compressor applications that require reliable torque, stable RPM, and long-term durability. Built for single-phase 208–230V power and designed around a rugged 215T steel frame, this motor is a strong upgrade or replacement choice for mid-to-large belt-driven compressor systems. With a 1-3/8" shaft and 1740-RPM operating speed, it delivers the power and performance needed to support continuous shop use, from automotive environments to small industrial facilities.

This model is a dependable solution for users who need a motor that handles frequent cycling, sustained workloads, and consistent compressed air output without compromise.

Key Specifications

• Horsepower: 7.5 HP
• Frame Size: 215T steel frame
• RPM: 1740 (nominal)
• Shaft Diameter: 1-3/8" keyed shaft
• Full Load Amps: 34.0 A @ 208V / 28.6 A @ 230V
• Voltage: 208–230V
• Phase: Single-phase
• Service Factor: 1.15 (1.00 @ 208V)
• Rotation: Reversible (CW or CCW)

Product Overview

This Baldor motor provides a strong balance of power, reliability, and ease of integration. Its 215T frame and industry-standard shaft diameter allow it to fit many popular compressor pumps and mounting footprints. The reversible rotation option adds flexibility for different pulley arrangements, while its 1.15 service factor delivers extra capacity during high-load operation.

The 7.5 HP output makes it suitable for larger air compressors that power multiple pneumatic tools or supply continuous airflow in busy work environments. If your shop regularly deals with air-hungry tools, spray equipment, or extended duty cycles, this motor offers the performance stability needed to keep your system running efficiently.

Ideal Applications

1. Air Compressor Motor Replacement
   Designed to match many 215T-frame compressor setups for quick swap-ins without major modifications.
2. Upgrading Underpowered Systems
   A practical solution for shops moving from 5 HP or older motors that no longer support required CFM output.
3. Continuous-Duty Environments
   Suitable for woodworking shops, auto repair facilities, light manufacturing, and environments that rely on steady, uninterrupted compressed air.
4. General Belt-Driven Equipment
   Can also operate pumps, blowers, and mechanical drive systems requiring approximately 7.5 HP on single-phase power.

Benefits and Performance Advantages

• Dependable Industrial Construction
  The steel 215T frame supports stable mounting, reduced vibration, and long service life.
• Consistent Power Delivery
  Reliable 1740-RPM operation ensures smooth performance and consistent airflow production.
• Reversible Rotation
  Allows alignment with a wide range of compressor pumps and pulley orientations.
• Strong Starting and Load Capacity
  The 1.15 service factor provides additional overhead during motor start-up and heavy load cycles.
• Single-Phase Compatibility
  Ideal for locations where three-phase power is unavailable or impractical.
• Straightforward Installation
  Standard shaft size, frame footprint, and accessible wiring points simplify installation and maintenance.

Installation and Setup Considerations

1. Verify Voltage Availability
   Ensure your electrical service supports 208–230V single-phase power before installation.
2. Check Mounting Compatibility
   Confirm that your compressor base and pulley system match the 215T footprint and shaft requirements.
3. Align and Tension Belts Correctly
   Proper alignment prevents premature wear, vibration, or performance loss.
4. Allow for Adequate Ventilation
   For optimal cooling and longevity, position the motor where airflow is not obstructed.
5. Inspect the Pulley and Keyway Fit
   Ensure the 1-3/8" shaft and key mate correctly with your existing equipment.

Who This Motor Is For

• Shops needing a high-reliability 7.5 HP motor for medium-to-large compressors
• Businesses experiencing performance issues or overheating with lower-horsepower motors
• Users looking for a long-lasting replacement from a recognized industrial-grade manufacturer
• Facilities operating belt-driven pumps and equipment requiring strong, steady horsepower on single-phase power

Final Assessment

The Baldor 7.5 HP Air Compressor Motor in the 215T frame is a strong, dependable choice for anyone needing high output, single-phase compatibility, and industrial-ready construction. Its balanced combination of torque, durability, reversible rotation, and consistent 1740-RPM operation ensures stable performance across a wide range of compressor systems. For shops that cannot afford downtime or inconsistent airflow, this motor provides the confidence and reliability required for demanding daily use.
