2B Two-Groove B-Section Cast Iron V-Belt Sheave — SK Bushing Type (Bushing Sold Separately)
| Specifications (As Configured) | |
|---|---|
 Vendor |
Warthog Air Compressor Store
|
 SKU |
2B70-SK
|
The 2B two-groove B-section cast iron V-belt sheave is a precision-machined, statically balanced pulley built for higher-load, dual-belt power transmission on air compressors, blowers, fans, pumps and industrial machinery. It runs two matched B (also 5L) V-belts and uses the popular SK-type tapered QD bushing for a secure, concentric grip on the shaft. The bushing is sold separately, letting you match the exact bore you need to your shaft or motor frame.
Key specifications
- Configuration: Two-groove (2 belts)
- Belt section: B / 5L (5/8" top width)
- Material: Class 30 gray cast iron, precision-machined and balanced
- Bushing system: SK-type tapered QD bushing — sold separately
- Bore: set by the SK bushing you select (finished bore)
- Outside diameters: 7.35" through 18.75"
Typical applications
Air compressors, blowers and fans, centrifugal and positive-displacement pumps, conveyors, and general industrial drive systems where two B-section belts share the load for added torque capacity.
Not sure which bushing size you need? Add your shaft diameter or motor frame to the end of the part number and we'll include the correct SK bushing (example: 2B70-SK-1-3/8"). This 2B two-groove B-section cast iron sheave delivers reliable, balanced V-belt power transmission across a wide range of outside diameters.
NOTE: Actual product may be different from pictured!
