2" Dry Pressure Gauge — 1/8" Center Back Mount, Black Steel Case
| Specifications (As Configured) | |
|---|---|
 Vendor |
Warthog Air Compressor Store
|
 SKU |
102D-208B
|
A 2" dial dry utility pressure gauge with a 1/8" NPT center back mount connection, built for industrial and commercial use. Suitable for air, water, oil, gas, or any other media not corrosive to brass.
Which range should you choose?
Pick the range type that matches what your system does:
- Pressure (e.g. 0–100 PSI): Positive pressure only — what almost every air-compressor and shop-air job needs.
- Compound (e.g. 30 inHg vacuum to 100 PSI): Reads both vacuum and positive pressure on one dial — for systems that pull suction and also build pressure.
- Vacuum only (0 to 30 inHg): Suction / negative pressure only.
What does "inHg" mean? It stands for inches of mercury — the standard unit gauges use to measure vacuum, meaning pressure below normal atmospheric pressure (in other words, suction). 0 inHg is ordinary atmospheric pressure, and about 30 inHg is a near-complete vacuum — roughly 14.7 PSI of suction. So a gauge marked "30 inHg" reads the entire vacuum range, from no suction down to full vacuum. (By comparison, PSI measures pressure above atmospheric.)
Key specifications
- Dial size: 2" (50 mm)
- Connection: 1/8" Male NPT, center back mount
- Case: black steel with chrome-plated bezel
- Wetted parts: brass socket and phosphor-bronze bourdon tube
- Lens: clear plastic
- Accuracy: ±3-2-3% of span (ASME B40.100 Grade B)
- Operating temperature: -50°F to 160°F
- Fill: dry (non-fillable)
Available ranges: vacuum (30 inHg), compound (30 inHg to 300 PSI), and positive-pressure 0–15, 0–30, 0–60, 0–100, 0–160, 0–200, 0–300, and 0–600 PSI.
Applications: air compressors, pneumatic systems, pumps, filtration, and general process monitoring.
This 2-inch dry pressure gauge delivers reliable, ASME-grade readings in a compact black steel case with a corrosion-resistant brass socket — a dependable replacement gauge for compressors and pneumatic equipment across a wide range of vacuum, compound, and pressure scales.
NOTE: Actual product may be different from pictured!
