Chicago Pneumatic Integral Drill Steel — 7/8" × 4-1/4" Shank, 1-5/8" Gauge Bit
| Specifications (As Configured) | |
|---|---|
 Vendor |
Chicago Pneumatic Power Technique
|
 SKU |
3310102532
|
Chicago Pneumatic integral drill steel is a one-piece forged alloy-steel rod with a tungsten-carbide chisel bit forged directly onto the rod — no threaded couplings to loosen or lose. The monolithic design transmits percussive energy straight from the drill piston to the rock face for fast, consistent penetration in granite, basalt, limestone, and concrete. It runs on a standard 7/8" × 4-1/4" hex shank to fit Chicago Pneumatic handheld pneumatic sinker and stoper rock drills.
Key specifications
- Type: integral drill steel (one-piece rod with forged carbide chisel bit)
- Shank: 7/8" × 4-1/4" hex
- Bit gauge (cutting diameter): 1-5/8"
- Available lengths: 11-13/16", 24" (2'), 29-15/16" (2'5-15/16")
- Material: forged, heat-treated alloy steel with WC-Co carbide insert
- Fits Chicago Pneumatic pneumatic sinker / stoper rock drills
Typical applications
Granite and stone quarrying, underground drifting, roof-bolt and anchor holes, doweling, and small-diameter percussive blast-hole drilling. Choose the working length to match your hole depth. Backed by Chicago Pneumatic's reputation for durable, jobsite-ready rock-drilling tools.
NOTE: Actual product may be different from pictured!
